Stainless steel high-pressure hatches

BPV 400 hatch with hard plastic handwheels

BPV 400 hatch with stainless steel handwheels

Hatches and Valves, High-pressure hatches

Stainless steel high-pressure hatches

BPV 300, BPV 400, BPV 500, BPV 600

Features

Screw-lock hatch, built to withstand special pressure or vacuum conditions. Its opening angle is about 140°. It can be made of AISI 304 or AISI 316 L stainless steel, with hard plastic or stainless steel handwheels.

Finish

The hatch is completely shot peened.Depending on requirements and upon request, it can also be supplied satin or polished.

Important

Standard frames have a height of 100 mm, but can be supplied up to a height of 1000 mmon request.PED 97/23/EC compliance on request

Employment

In pharmaceutical, chemical, and canning industries and on special machines intended for the food processing industry where special hygiene and sterilization measures are required.

Notes

Frame: thickness = 4 mm
Cover: thickness = 4 mm

Request information

	ØA [mm]	ØA1 [mm]	B [mm]	D [mm]	E [mm]	G [mm]	N [mm]	H1 [mm]	Max Pressure Allowed [bar]	Depression [bar]	Weight approx* [kg]	Number of leaflets
BPV 300	308	337	420	319	150	65	376	100/1000	6,5	-0,9	19	4
BPV 400	408	437	520	369	150	70	476	100/1000	3,7	-0,9	22	4
BPV 500	508	537	620	419	150	90	576	100/1000	3,2	-0,9	30	5
BPV 600	608	637	720	469	150	80	676	100/1000	3,0	-0,9	38	6
